3-Wheel Lifting Platform Specification
Driven by a reliable 4 x lead-acid battery power system, this compact 3-Wheel Lifting Platform features a 250kg payload capacity and an adjustable cargo bed that lifts up to 90cm. With an overall width of just 80cm and a 300kg curb weight, it navigates narrow orchard rows, greenhouses, and tight warehouse aisles with ease. Combining cargo transportation and lifting functions, it is an efficient, labor-saving solution for modern precision farming and harvesting.
Product Description
The 3-Wheel Electric Lifting Platform is an innovative, highly agile transport and lifting solution designed specifically for modern agriculture, greenhouse farming, orchard harvesting, and narrow-aisle material handling. Powered by a high-capacity lead-acid battery pack, this eco-friendly machine eliminates manual heavy lifting and tedious pulling during harvests. Its unique hydraulic/mechanical lifting cargo bed allows workers to easily load, transport, and elevate crops or goods to an ergonomic working height, significantly boosting operational efficiency and reducing labor costs.
Core Features:
• Ultra-Narrow Design for High Agility: With a slim overall width of just 80cm, it effortlessly navigates through dense orchard rows, tight greenhouse walkways, and narrow facility corridors where standard vehicles cannot fit.
• Dual-Function Transport & Lifting: Features an adjustable cargo bed that can lift from a base height of 57cm up to a maximum height of 90cm, streamlining high-position fruit picking, crop loading, and shelf stacking.
• Robust Load Capacity: Despite its lightweight 300kg curb weight, the reinforced chassis and dual rear wheels support a heavy-duty payload capacity of approximately 250kg.
• Eco-Friendly Power System: Equipped with a dependable 4-cell lead-acid battery configuration, delivering quiet, zero-emission operation suitable for enclosed indoor greenhouse environments.
• Ergonomic Folding Seat: Designed with a comfortable operator seat (58cm height) that can be neatly folded down to a compact 32cm height to minimize transport clearance and maximize storage convenience.
| Parameter | Details |
|---|---|
| Overall length | 3m |
| Internal cargo bed length | 1.61m |
| Overall width | 80cm |
| Internal cargo bed width | 56cm |
| Maximum height (at full lift) | 90cm |
| Cargo bed height | 57cm |
| Cargo bed depth/floor thickness | 16cm |
| Seat height | 58cm |
| Folded seat height | 32cm |
| Curb weight | 300kg |
| Power System Battery | 4 × Lead-acid batteries |
| Payload capacity | approx. 250kg |
