Power Harrow 1BQ-3B/1BQ-4B
The Power Harrow 1BQ-3B/1BQ-4B is a highly efficient implement designed for professional seedbed preparation and secondary tillage before sowing. Powered by the tractor’s rear PTO through a robust gear mechanism, it features vertically downward rake teeth on in-line support discs that rotate to deliver exceptional soil conditioning. Highly versatile, it can easily transition into a straw crushing and field-returning tool by simply replacing components, offering global farmers a multi-functional, high-performance tillage solution.
Product Description
Equipment Application
The power harrow is mainly used in agricultural tillage for seedbed preparation and secondary tillage before sowing. After replacing the components, it can also be used for straw crushing and returning to the field, making it a multi-functional agricultural implement.
Working Principle
This implement utilizes the rear PTO shaft of the tractor to transmit power and motion to the in-line arranged rake tooth support discs through a gear mechanism. Two vertically downward rake teeth are fixed on each support disc, and the rotation of the rake teeth completes the tillage operation.
| Parameter | Unit | 1BQ-3B Power Harrow | 1BQ-4B Power Harrow |
|---|---|---|---|
| Model | / | 1BQ-3B Power Harrow | 1BQ-4B Power Harrow |
| Structural Type | / | Mounted | Mounted |
| Matching Power Range | kW | 88.2–117.6 | 132.3–176.5 |
| Matching PTO Shaft Speed | r/min | 1000 | 1000 |
| Connection Mode with Tractor | / | Three-point Hitch | Three-point Hitch |
| Main Shaft Speed | r/min | 390 | 390 |
| Overall Dimensions (L×W×H) | mm | 1570×3100×1300 | 1570×4200×1300 |
| Working Speed | km/h | 6–8 | 6–8 |
| Working Width | cm | 300 | 400 |
| Tooth Spacing | cm | 24.5 | 24.5 |
| Working Depth | cm | 10–18 | 10–18 |
| Number of Rake Units | / | 12 | 16 |
| Total Number of Rake Teeth | / | 24 | 32 |
