Model D Farm Tractor (90-120HP)
Experience ultimate heavy-duty capability with the Model D Farm Tractor (90-120HP). This 4-ton beast combines an ultra-large displacement 5.61L engine with a long 2320mm wheelbase to provide unmatched traction and ground grip for land reclamation. It stands out with a continuous-run 218.7L fuel reservoir and a remarkable 390mm ground clearance to conquer deep ruts and obstacles. Operators benefit from smooth hydrostatic wet disc brakes, a versatile 16F+8R transmission, and flexible PTO options (up to 21 splines). Backed by a powerful 58 L/min hydraulic flow, a 1795kg lift capacity, and a towering 2900mm safety ROPS, the Model D is the definitive, high-efficiency workhorse designed to dominate the most demanding fields.
Product Description
1. Extreme Power & Precision Transmission
Ultra-Large Displacement 100HP Engine:** Powered by a massive 5.61L 4-cylinder engine, providing unparalleled torque and “heavy-lift” capability that surpasses standard 100HP models.
Advanced 16F + 8R Gearbox:** High-capacity transmission with 16 forward and 8 reverse gears, offering the finest speed control for specialized heavy-duty soil preparation.
Independent Control & Dual-Acting Clutch:** Features a fully independent control mechanism and dual-acting clutch for professional-grade PTO management.
2. Maximum Endurance & Ground Clearance
High-Capacity 218.7L Fuel Tank:** The massive 218.7-liter fuel reservoir supports continuous, high-intensity operations over vast acreages without mid-day refueling.
Superior 390mm Ground Clearance:** An impressive 390mm clearance ensures the tractor navigates deep ruts and high obstacles in challenging terrains with ease.
Professional 4WD Heavy-Duty Chassis:** Built on a long 2320mm wheelbase for maximum traction and rock-solid stability during heavy towing.
3. Heavy-Lift Hydraulics & Versatile Output
Industry-Leading Lift Capacity (1795kg):** Equipped with Category II three-point hitch to handle massive, multi-row implements with ease.
High-Flow 58 L/min Hydraulic Pump:** The powerful 58L/min pump ensures rapid, powerful, and precise response for all complex hydraulic systems.
Flexible PTO Options:** Offers 540/1000 rpm speeds with optional 6, 8, or 21-spline shafts to match any international implement standard.
4. Ultimate Heavy-Duty Build & Safety
Hydrostatic Wet Disc Braking:** Features an advanced hydrostatic actuation method for its wet disc brakes, delivering smooth, effortless, and powerful stopping force.
Heavy-Weight Stability (4000kg):** With a 4-ton operating weight, this tractor provides the ultimate ground grip required for deep plowing and large-scale land reclamation.
Reinforced Safety ROPS:** The towering 2900mm ROPS structure provides an expansive view and maximum rollover protection for the operator.
| Category | Specification | Details |
|---|---|---|
| Engine | Drive Type | 4WD 4×4 |
| Type | Diesel, 4-cylinder, 4-stroke, Direct Injection, LR4V5P/Water-cooled | |
| Aspiration | Naturally Aspirated | |
| Power (HP) | 100 | |
| Displacement (cc) | 5610 | |
| Fuel Tank Capacity (L) | 218.7 | |
| Rated Speed (rpm) | 2300 | |
| Starting System | Electric Start | |
| PTO Output (HP) | 85 | |
| Transmission | PTO Power (HP) | 85 |
| Number of Gears | 16F + 8R | |
| Transmission Structure | 4×(2+1)×2, Sliding Sleeve Shift | |
| Min/Max Speed (km/h) | Forward 1.65–33.26; Reverse 1.81–21.01 | |
| Steering | Full Hydraulic | |
| Clutch | Dry, Single Plate, Dual Acting | |
| Brake | Differential Lock | Spline Sleeve Type |
| Main Brake | Wet Disc | |
| Actuation Method | Hydrostatic Brake | |
| Parking Brake | Independent Hand Brake | |
| Power Take-Off (PTO) | Control Mechanism | Independent |
| PTO Speed | 540 / 1000 | |
| Spline Teeth / Diameter | 6/8/21 Splines Optional | |
| Drawbar Included | No | |
| Hydraulic System | Pump Type | Gear Pump (Open Center) |
| Pump Flow (L/min) | 58 | |
| Three-Point Hitch | Category II | |
| Lift Capacity at 610 mm (kg) | 1795 | |
| Dimensions | Lift Capacity with Ball Ends (kg) | / |
| Overall Length (mm) | 4800 | |
| Overall Width (mm) | 2000 | |
| Maximum Width (mm) | / | |
| Height (mm) | 2900 (ROPS Top) | |
| Wheelbase (mm) | 2320 | |
| Minimum Ground Clearance (mm) | 390 | |
| Minimum Turning Radius (mm) | / | |
| Minimum Operating Weight | Weight (kg) | 4000 |
