Model B Farm Tractor (55-80HP)

Dominate challenging agricultural tasks with the heavy-duty Model B Farm Tractor (55-80HP). Boasting an unmatched 2345kg operating weight and a robust 4WD chassis, this tractor provides incredible ground grip for heavy pulling and uphill work. It features an upgraded 12F+12R shuttle shift transmission and full hydraulic steering for effortless precision. Built for extreme conditions, it leads its class with an extraordinary 375mm ground clearance and an enormous 105L fuel tank to eliminate frequent refueling during peak seasons. Equipped with premium wet disc brakes, a 38 L/min high-flow hydraulic system, and a stable dual-speed PTO, the Model B is the ultimate, reliable workhorse designed to maximize your multi-day farming efficiency.

Product Description

Product Description

1. Heavy-Duty Power & Advanced Transmission
High-Displacement 50HP Engine:** Powered by a 3.17L large-displacement 4-cylinder engine, providing superior torque reserve and consistent power for heavy-duty field work.
12F + 12R Shuttle Shift:** Features a high-spec 12 forward and 12 reverse gear configuration, offering more precise speed matching for complex agricultural tasks.
Full Hydraulic Steering & Dual Acting Clutch:** Combines effortless maneuverability with a dual-acting clutch for independent and smoother PTO operation.
2. Extreme Ground Clearance & Endurance
Extraordinary Ground Clearance (375mm):** The industry-leading 375mm clearance allows for exceptional mobility over high obstacles and minimizes crop damage in specialized farming.
Massive 105L Fuel Tank:** The huge fuel capacity ensures multiple days of operation without frequent refueling, maximizing productivity during peak seasons.
Robust 4WD Chassis:** Optimized for 4×4 drive to provide maximum traction on soft, muddy, or uneven terrains.
3. Professional-Grade Hydraulic & Control
High-Performance 540/1000 PTO:** Delivers 43HP at the PTO with dual speeds, perfectly suited for heavy rototillers, harvesters, and high-pressure sprayers.
Semi-Independent Control Mechanism:** Enhanced control mechanism allows for more professional and reliable management of rear-mounted implements.
38 L/min High-Flow Hydraulics:** Ensures rapid lifting and responsive performance for all Category I three-point hitch attachments.
4. Ultimate Stability & Safety
Premium Wet Disc Brakes:** Equipped with oil-immersed wet disc brakes for smoother braking, better heat dissipation, and long-term durability.
Unmatched Operating Weight (2345kg):** At over 2.3 tons, this tractor provides incredible stability and ground grip for heavy-duty pulling and uphill tasks.
Safety ROPS (2650mm height):** A high-clearance protective structure ensures the driver’s safety while providing an imposing presence and better visibility.

CategorySpecificationDetails
EngineDrive Type4WD 4×4
TypeDiesel, 4-cylinder, 4-stroke, Direct Injection, QC498T50/Water-cooled
AspirationNaturally Aspirated
Power (HP)50
Displacement (cc)3170
Fuel Tank Capacity (L)105
Rated Speed (rpm)2400
Starting SystemElectric Start
PTO Output (HP)43
TransmissionPTO Power (HP)43
Number of Gears12F + 12R
Transmission Structure(1+1)×4×3, Sliding Sleeve Shift
Min/Max Speed (km/h)Forward 2.46–32.73; Reverse 2.15–28.68
SteeringFull Hydraulic
ClutchDry, Single Plate, Dual Acting
BrakeDifferential LockPin Type
Main BrakeWet Disc
Actuation MethodMechanical Pedal Type
Parking BrakeIndependent Hand Brake
Power Take-Off (PTO)Control MechanismSemi-Independent
PTO Speed540 / 1000
Spline Teeth / Diameter6 Splines
Drawbar IncludedNo
Hydraulic SystemPump TypeGear Pump (Open Center)
Pump Flow (L/min)38
Three-Point HitchCategory I
Lift Capacity at 610 mm (kg)898
DimensionsLift Capacity with Ball Ends (kg)/
Overall Length (mm)3880
Overall Width (mm)1750
Maximum Width (mm)/
Height (mm)2650 (ROPS Top)
Wheelbase (mm)1990
Minimum Ground Clearance (mm)375
Minimum Turning Radius (mm)/
Minimum Operating WeightWeight (kg)2345
